New Energy Vehicle Charging Pile Testing

Currently, new energy vehicles have received widespread attention and are experiencing rapid growth. The fast-expanding market has, however, also led to increased pressure on power supply. To address this challenge, the government is providing strategic support and encouraging companies to research and develop charging piles with higher efficiency. Furthermore, the country is also pushing local governments to implement the planned layout and operation of charging piles. The aim is to quickly provide more convenient charging services for the general public. This has created new opportunities and challenges for the charging pile industry.
Description

Charging piles for new energy vehicles can be classified into two types based on their output: direct current (DC) charging piles and alternating current (AC) charging piles. DC charging piles can directly charge the power battery, providing higher output power, suitable for fast charging. In contrast, AC charging equipment has a relatively lower output power and requires A/D conversion through the On-Board Charger (OBC) in the vehicle before it can charge the power battery. SUITA Electric’s bidirectional programmable DC power supplies, regenerative AC power supplies, and ultra-high-precision power analysis wavecorders can meet various needs, and offer professional and reliable testing solutions for both types of charging piles. In addition, they are featured by user-friendliness and rich functionalities designed for various types of tests.

heroimage
Solution Introduction

SUITA Electric’s power products comply with multiple GB standards and industry specifications, as listed below:

GBT18487.1-2015: Electric vehicle conductive charging system - Part 1: General requirements
GBT20234.1-2015: Connection set of conductive charging for electric vehicles - Part 1: General requirements
GBT20234.2-2015: Connection set for conductive charging of electric vehicles - Part 2: AC charging coupler
GBT20234.3-2015: Connection set for conductive charging of electric vehicles - Part 3: DC charging coupler
GBT27930-2015: Communication protocols between off-board conductive charger and battery management system for electric vehicle
Q/GDW1592-2014: Electric vehicle AC charging spot testing technical specification

Main Advantages
SUITA Electric's strong professional capabilities make its products more advantageous in related fields
Multi Scenario Design
Complemented by a variety of products and supervisory software, SUITA’s modular design allows for the construction of different testing systems based on actual application scenarios and testing requirements.
Multi Scenario Design
Application Scenarios
DC charging pile
AC charging pile
SUITA Electric is committed to covering complex scenarios in various fields across the entire industry with its products.
